DCS-E1 5x2 Double Solenoid Valve
2534.0 INR/Piece
Product Details:
- End Connection Threaded
- Power Consumption <4 W (Per Coil)
- Operating Voltage 24V DC / 230V AC (Available Variants)
- Working Presssure 0.15~0.8 MPa
- Material Aluminum Alloy (Body), Engineering Plastic (Coil Cover), NBR/Viton (Seals)
- Valve Structure Spool Valve
- Way Type 5 Way, 2 Position (5/2)
- Click to View more
X
DCS-E1 5x2 Double Solenoid Valve Price And Quantity
- 2534.0 INR/Piece
- 1 Piece
DCS-E1 5x2 Double Solenoid Valve Product Specifications
- 0C to 60C
- 0.15~0.8 MPa
- Pneumatic Automation Systems, Air Control
- 0.15~0.8 MPa
- Precision Machined
- 24V DC / 230V AC (Available Variants)
- Threaded
- <4 W (Per Coil)
- 1/4 BSP (Standard)
- 0C to 60C
- Threaded
- Aluminum Alloy (Body), Engineering Plastic (Coil Cover), NBR/Viton (Seals)
- Filtered Air, Compressed Air
- Spool Valve
- Silver & Black
- Approx. 110mm x 30mm x 60mm
- 5 Way, 2 Position (5/2)
- Approx. 450 gm
- Individual, with Silencer Possible
- -10C to 50C
- IP65
- Sub-base or Inline
- Less than 40 ms
- Double Solenoid
- Class F
- DIN Connector
- NBR (Optional: Viton)
- Yes (Non-locking Type)
- Over 10 Million Operations
DCS-E1 5x2 Double Solenoid Valve Trade Information
- 7 Days
Product Description
UFLOW DCS-E1 5/2-Way Double Solenoid Valve (1/4" BSP)
Achieve high-precision, memory-retaining control over your double-acting pneumatic systems with the industrial-grade UFLOW DCS-E1 5/2-Way Double Solenoid Valve. Built with a dual-coil configuration, this directional control valve switches internal air paths through momentary electrical pulses on either side, holding its physical position without demanding a continuous electrical current. This bistable functionality acts as a dependable mechanical safeguard, ensuring your cylinders and actuators maintain their current operating state even during unexpected power cuts or signal loss.
Engineered with standard 1/4" BSP inlet and outlet ports, the DCS-E1 delivers a smooth airflow capacity of 1200 LPM to maximize machine responsiveness. The robust aluminum housing, paired with precision brass internals and durable Nitrile rubber seals, handles relentless factory environments across a lifecycle exceeding 10 lakh operations. Complete with two dual-insulated, IP65-rated square epoxy coils that safeguard the component against humidity and particulate ingress, this valve serves as an energy-efficient, fast-cycling cornerstone for high-speed assembly line networks, packaging bays, and material routing operations.
Key Features & Applications:
-
Bistable Position Retention: Dual-solenoid setup shifts the inner spool with short electrical impulses, maintaining its location continuously until the opposite coil is fired.
-
Rapid Multi-Port Switching: Supports high-speed, continuous cycling up to 600 operations per minute to maintain tight manufacturing cycle speeds.
-
Premium Industrial Seals: Heavy-duty Nitrile gaskets protect against internal bypass and drop-off across standard 2 to 10 bar working pressures.
-
IP65 Dual Environmental Guard: Dust-proof and splash-resistant coil structures provide reliable performance near heavy machinery or humid assembly areas.
High-Performance Double Solenoid Valve
The DCS-E1 5x2 Double Solenoid Valve boasts ultra-fast actuation with a spool-based mechanism and rapid response of less than 40 milliseconds. Designed with high durability in mind, its aluminum alloy body and engineering plastic coil cover ensure longevity and resistance to harsh conditions in pneumatic systems.
Versatile Mounting and Control Options
This valve allows for sub-base or inline mounting, offering flexibility for diverse installation needs. Its non-locking manual override facilitates manual actuation during maintenance or setup, while the threaded connection and standard 1/4 BSP port ensure compatibility with prevalent pneumatic configurations.
Precision, Safety, and Efficient Operation
Engineered for over 10 million cycles and IP65 protection, the DCS-E1 maintains performance under demanding environments. Its individual exhaust system-with optional silencer-controls noise and ensures each valve's exhaust is isolated, enhancing operational safety and efficiency in air automation applications.
FAQ's of DCS-E1 5x2 Double Solenoid Valve:
Q: How does the DCS-E1 5x2 Double Solenoid Valve operate within pneumatic automation systems?
A: The DCS-E1 uses a double solenoid actuation mechanism, allowing for precise control between two positions in a 5-way configuration. It is powered by either 24V DC or 230V AC variants, making it adaptable to different system requirements. The valve is designed to handle filtered or compressed air and provides rapid responses for efficient automation.Q: What are the main benefits of using a DCS-E1 5x2 Double Solenoid Valve in industrial applications?
A: Key benefits include ultra-fast response time (<40 ms), over 10 million cycle life, IP65 protection, and the flexibility of sub-base or inline mounting. Its durable construction and optional features like individual exhaust with silencers enhance reliability, safety, and reduce operational noise within pneumatic control systems.Q: When should I use the manual override feature and how is it performed?
A: The non-locking manual override is intended for use during setup, maintenance, or in the event of electrical failure. To use it, simply engage the override actuator, which allows temporary manual operation of the valve without locking it in position, ensuring safe reset to normal automated control afterward.Q: Where can the DCS-E1 valve be installed and what mounting types are supported?
A: This valve is suitable for installation in a variety of pneumatic automation setups. It supports both sub-base and inline mounting, providing versatility for integration in different machinery and process layouts typically encountered by manufacturers, system integrators, and maintenance teams.Q: What process media and conditions are suitable for this valve?
A: The DCS-E1 is designed for use with filtered or compressed air, handling media temperatures from 0C to 60C and system pressures between 0.15 MPa to 0.8 MPa. Its robust design tolerates ambient temperatures from -10C to 50C, accommodating wide-ranging industrial environments.Q: How does the individual exhaust type with optional silencer benefit pneumatic applications?
A: The individual exhaust design channels out air separately from each valve port, reducing the risk of cross-contamination and enhancing process control. Adding a silencer further diminishes exhaust noise, contributing to a safer and quieter working environment.Q: What are the available sealing options, and how should I choose between NBR and Viton seals?
A: The valve comes standard with NBR seals, suitable for general pneumatic applications, while optional Viton seals provide enhanced chemical and temperature resistance. Choose Viton if your process involves more aggressive media or higher temperature ranges up to 60C.Tell us about your requirement
